DAHUA  IP CAMERA 3 Megapixel

:: Dahua IP Camera 3 Megapixel  ::

IPC-HFW4300E

IPC-HFW4300E Overview > 1/3” 3Megapixel progressive scan Aptina CMOS > H.264 &MJPEG dual-stream encoding  > Max 20fps@3M(2048×1536)&25/30fps@1080P(1920×1080)  > DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC > Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS > 3.6mm fixed lens (6mm,8mm optional) > Max. IR LEDs Length 30m > IP66, PoE      Model DH-IPC-HFW4300E Camera Image Sensor 1/3” 3Megapixel progressive scan CMOS Effective Pixels 2048(H)x1536(V) Scanning System Progressive Electronic Shutter Speed Auto/Manual, 1/3(4)~1/10000s  Min. Illumination 0.01Lux/F1.6 (Color),0Lux/F1.6(IR on) S/N Ratio More than 50dB Video Output N/A Camera Features Max. IR LEDs Length 30m Day/Night Auto(ICR)/Color/B/W Backlight Compensation BLC / HLC / DWDR White Balance Auto/Manual Gain Control Auto/Manual Noise Reduction 3D Privacy Masking Up to 4 areas Lens Focal Length 3.6mm (6mm,8mm optional) Max Aperture F1.8(F1.6/F1.6) Focus Control Manual Angle of View H:72.5°(44°/33.2°) Lens Type Fixed lens Mount Type Board-in Type Video Compression H.264/ MJPEG Resolution 3M(2048×1536)/1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF(352×288/352×240) Frame Rate Main Stream 3M(1~20fps)/1080P/720P(1 ~ 25/30fps) Sub Stream D1/CIF(1 ~ 25/30fps) Bit Rate H.264: 32K ~ 8192Kbps Audio Compression N/A Interface N/A Network Ethernet RJ-45 (10/100Base-T) Wi-Fi N/A Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour Compatibility ONVIF,PSIA,CGI Max. User Access 20users Smart Phone iPhone, iPad, Android, Windows Phone Auxiliary Interface Memory Slot N/A RS485 N/A Alarm N/A PIR Sensor Range N/A General Power Supply DC12V, PoE (802.3af) Power Consumption Max 5.5W Working Environment -20°C~+60°C, Less than 95% RH Ingress Protection IP66 Vandal Resistance N/A Dimensions 168.1mm×66mm×58.4mm Weight 0.5kg
