DAHUA NVR  Series4


 DAHUA Network Video Recorder
NVR4104/4108/4116H
  NVR4104/4108/4116H-P


NVR4104/4108/4116H

Overview
>Up to 4/8/16 channel with 1080P realtime live view
>Max 80Mbps incoming bandwidth
>Up to 5Mp resolution preview&playback
>H.264/MJPEG dual codec decoding
>HDMI/VGA simultaneous video output
>All channel synchronous realtime playback, GRID interface
>Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.
>ONVIF Version 2.3 conformance
>3D intelligent positioning with Dahua PTZ camera
>Support 1 SATA HDD up to 4TB, 2 USB2.0
>Support IPC UPnP, 4PoE ports
>Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS




Model DH-NVR4104H DH-NVR4108H DH-NVR4116H
System
Main Processor Dual-core embedded processor
Operating System Embedded LINUX
Video
IP Camera Input 4 channel 8 channel 16 channel
Two-way Talk 1channel Input, 1channel Output, RCA
Display
Interface 1 HDMI,1 VGA
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression H.264/MJPEG
Resolution 5Mp(2560×1920)/3Mp(2048×1536)/1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480)
Record Rate 80Mbps
Bit Rate 48~ 8192kbps
Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Playback & Backup
Sync Playback 1/4 1/4/9 1/4/9/16
Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device/Network/Internal SATA burner
Network
Ethernet 1 RJ-45 port (10/100Mbps)
Network Function HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
Max. User Access 128users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 1 SATA ports, up to 4TB
Auxiliary Interface
USB 2 ports, USB2.0
General
Power Supply DC12V/2A
Power Consumption 10W(without HDD)
Working Environment -10°C~+55°C / 10%~90%RH / 86~106kpa
Dimension
(W×D×H)
Mini 1U, 325mm×240mm×45mm
Weight 1.25KG(without HDD)
